| Broj dela | Šifra dela | Naziv dela |
|---|---|---|
| 1 | 671100802 | BLADE TIGHTEN BOLT M10*1.35*40 |
| 2 | 671002550 | BLADE |
| 3 | DA00000808 | MOTOR CENTRIFUGAL CUTTER |
| 4 | 671002036 | CENTRIFUGAL CUTTER BUSHING |
| 5 | 671910001 | DECK |
| 6 | 671003028 | 5.5" WHEEL COVER |
| 7 | 671919001 | 5.5" WHEEL |
| 8 | 671002281 | THREAD PRESSING PLATE |
| 9 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 10 | 671909001 | HEAD COVER |
| 11 | 671920001 | 7" WHEEL |
| 12 | 671003029 | 7" WHEEL COVER |
| 13 | 671002281 | THREAD PRESSING PLATE |
| 14 | DA00000809 | MOTOR |
| 15 | 671001053 | SELF-TAPPING SCREW ST6*30 |
| 16 | 671912001 | MOTOR WIND GUIDE COVER |
| 17 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 18 | 671911001 | MOTOR COVER |
| 19 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 20 | 671913001 | MOTOR COVER HANDLE |
| 21 | DA00000810 | CONNECTION CABLE SHEATH |
| 22 | 671010230 | CABLE PRESSING PLATE |
| 23 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 24 | 671003059 | CAPACITOR |
| 25 | 671918001 | REAR FLAP |
| 26 | 671011214 | SPRING OF REAR FLAP |
| 27 | 671001067 | FIXED SHAFT OF REAR FLAP |
| 28 | 671090005 | CLAMP PIN |
| 29 | 671001046 | SELF-TAPPING SCREW ST4.8*19 |
| 30 | 671001712 | LOWER HANDLE BAR |
| 31 | 671277001 | CABLE CLAMP |
| 32 | 671050160 | LID SHAPE SCREW M6*11 |
| 33 | 671007007 | FLAT WASHER M8 |
| 34 | DA00000811 | TUBE PLUG |
| 35 | DA00000812 | PRESSING TIGHTEN PLATE |
| 36 | 671002466 | TIGHTEN LOCKING BOLT M6*62 |
| 37 | 671431001 | ADJUSTMENT SELF-LOCKING HANDLE |
| 38 | 671090040 | COLUMN PIN |
| 39 | 671108303 | BLOCK RING |
| 40 | DA00000826 | SELF-DRIVING SCREW ST4*12 |
| 41 | 671001052 | COIL OF CABLE HITCH |
| 42 | 671001613 | UPPER HANDLE BAR |
| 43 | 671073001 | HANDLE SUPPORT(LEFT) |
| 44 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 45 | 671074001 | HANDLE SUPPORT(RIGHT) |
| 46 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 47 | 671428001 | PRESSING PLATE OF SWITCH BOX |
| 48 | 671010050 | CONNECTION CABLE |
| 49 | DA00000818 | CONNECTION CABLE SHEATH1 |
| 50 | 671425003 | SAFETY BUTTON |
| 51 | 671011079 | SPRING OF TRANSFER BOARD |
| 52 | 671070001 | WATER-PROOF SWITCH BOX(RIGHT) |
| 53 | 671001043 | LAMPSHADE |
| 54 | 671010040 | ARC SWITCH |
| 55 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 56 | DA00000814 | CABLE PRESSING BOARD |
| 57 | DA00000813 | INDICATION LIGHT |
| 58 | 671069001 | WATERPROOF SWITCH BOX(LEFT) |
| 59 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 60 | DA00000815 | WATERPROOF PLUG |
| 61 | DA00000816 | SELF-DRIVING SCREW ST3*10 |
| 62 | 671011124 | SPRING OF RIGHT PLUG-IN |
| 63 | 671072001 | HANDLE RIGHT PLUG-IN |
| 64 | 671001021 | SELF-TAPPING SCREW ST4*10 |
| 65 | 671001648 | START BAR |
| 66 | DA00000817 | HANDLE LEFT PLUG-IN |
| 67 | 671011124 | SPRING OF RIGHT PLUG-IN |
| 68 | DA00000816 | SELF-DRIVING SCREW ST3*10 |
| 69 | 671001021 | SELF-TAPPING SCREW ST4*10 |
| 70 | 671015620 | GRASS CATCHER(MAKITA) |
| 71 | 671002302 | GRASS CATCHER BRACKET |
| 72 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 73 | 671914001 | COVER OF GRASS CATCHER |
| 74 | 671107101 | LEVEL INDICATOR |
| 75 | 671107301 | SELF-TAPPING SCREW ST4*16 |
| 76 | 671921001 | HANDLE OF GRASS CATCHER |
| 77 | DA00000821 | GRASS CATCHER ASS'Y (MAKITA) |
| INC. 70-76 | ||
| 671002009 | SPANNER |
