| Broj dela | Šifra dela | Naziv dela |
|---|---|---|
| 1 | 286288-8 | CAP 35 |
| 2 | 452986-8 | CHUCK COVER |
| 2 | 456529-8 | CHUCK COVER |
| 3 | 325813-1 | RING 21 |
| 4 | 346177-0 | GUIDE WASHER |
| 5 | 233916-6 | CONICAL COMP. SPRING 21-29 |
| 6 | 233989-9 | RING SPRING 14 |
| 7 | 346221-3 | WASHER 16 |
| 7 | 346834-0 | WASHER 16 |
| 13 | 265795-4 | THUMB SCREW M6X52 |
| 14 | 267415-6 | FLAT WASHER 33 |
| 15 | 452985-0 | GRIP 34 |
| 16 | 143120-8 | GEAR HOUSING COMPLETE |
| 16 | 213636-8 | OIL SEAL 25 |
| 17 | 346178-8 | CUP SLEEVE |
| 18 | 211423-9 | BALL BEARING 6806DDW |
| 19 | 232152-1 | LEAF SPRING |
| 20 | 325785-0 | PUSH CORN |
| 21 | 234147-0 | COMPRESSION SPRING 5 |
| 22 | 253308-3 | THIN WASHER 6 |
| 23 | 213258-4 | O RING 17.5 |
| 24 | 452983-4 | CHANGE LEVER |
| 25 | 452982-6 | CHANGE LEVER COVER |
| 26 | 216022-2 | STEEL BALL 7.0 |
| 27 | 216019-1 | STEEL BALL 3 |
| 28 | 141068-8 | TOOL HOLDER COMPLETE |
| 28 | 144273-6 | TOOL HOLDER COMPLETE |
| 31 | 267153-0 | FLAT WASHER 30 |
| 32 | 234222-2 | COMPRESSION SPRING 31 |
| 33 | 227268-5 | SPUR GEAR 51 |
| 34 | 313218-7 | DRIVING FLANGE |
| 35 | 267153-0 | FLAT WASHER 30 |
| 36 | 213075-2 | X-RING 9 |
| 37 | 325782-6 | SLEEVE 9A |
| 38 | 325789-2 | IMPACT BOLT A |
| 39 | 325794-9 | RING 10A |
| 40 | 424267-0 | CUSHION RING 12 |
| 41 | 325798-1 | O-RING CASE A |
| 42 | 213073-6 | O RING 9 |
| 43 | 233979-2 | RING SPRING 28 |
| 44 | 326096-6 | STRIKER |
| 45 | 213258-4 | O RING 17.5 |
| 46 | 310345-1 | PISTON CYLINDER |
| 47 | 346036-8 | GUIDE PLATE |
| 48 | 326097-4 | PISTON JOINT |
| 48 | 324215-8 | PISTON JOINT |
| 49 | 234098-7 | COMPRESSION SPRING 14 |
| 50 | 210028-2 | BALL BEARING 606ZZ |
| 56 | 227269-3 | SPUR GEAR 10 |
| 57 | 223174-2 | CLUTCH CAM |
| 58 | 219021-3 | SWASH BEARING 10 |
| 59 | 257321-3 | RING 8 |
| 60 | 310344-3 | BEARING BOX |
| 61 | 210029-0 | BALL BEARING 608ZZ |
| 62 | 266437-3 | HEX. SOCKET HEAD BOLT M4X16 |
| 63 | 285735-6 | BEARING RETAINER |
| 64 | 227748-1 | HELICAL GEAR 27 |
| 65 | 213727-5 | O-RING 63 |
| 69 | 141664-2 | INNER HOUSING COMPLETE |
| 69 | 443153-6 | FELT |
| 70 | 213407-3 | O RING 26 |
| 71 | 213678-2 | OIL SEAL 12 |
| 72 | 262571-7 | SLEEVE 8 |
| 73 | 210067-2 | BALL BEARING 6000ZZ |
| 74 | 267213-8 | FLAT WASHER 10 |
| 75 | 240084-8 | FAN 60 |
| 76 | 515859-7 | ARMATURE ASSEMBLY 240V |
| INC. 72-75,77,78 | ||
| 77 | 681652-2 | INSULATION WASHER |
| 78 | 210030-5 | BALL BEARING 627ZZ |
| 79 | 267804-5 | WAVE WASHER 15 |
| 83 | 266334-3 | TAPPING SCREW 4X60 |
| 84 | 452984-2 | BAFFLE PLATE |
| 85 | 633793-0 | FIELD 220-240V |
| 86 | 452979-5 | MOTOR HOUSING |
| 87 | 850W86-0 | M8700 NAME PLATE |
| 88 | 890304-6 | CLEAR LABEL |
| 89 | 194722-3 | CARBON BRUSH CB-459 |
| 90 | 638747-2 | BRUSH HOLDER UNIT |
| 92 | 266361-0 | TAPPING SCREW 4X30 |
| 93 | 850W88-6 | M8700 SERIAL NO. LABEL |
| 94 | 890297-7 | CLEAR LABEL |
| 95 | 682566-8 | CORD GUARD 10 |
| 96 | 665890-4 | POWER SUPPLY CORD 1.0-2-4.0 |
| 96 | 695490-6 | POWER SUPPLY CORD 1.0-2-4.0 |
| 97 | 650671-9 | SWITCH TG853TB-1C |
| 98 | 645190-8 | NOISE SUPPRESSOR |
| 99 | 687682-1 | STRAIN RELIEF |
| 100 | 266385-6 | TAPPING SCREW 4X14 |
| 101 | 266326-2 | TAPPING SCREW 4X18 |
| 102 | 452981-8 | HANDLE COVER |
| 103 | 266326-2 | TAPPING SCREW 4X18 |
| 104 | 267447-3 | FLAT WASHER 14 |
| 105 | 233992-0 | RING SPRING 15 |
| 106 | 267437-6 | FLAT WASHER 17 |
| 106 | 267114-0 | FLAT WASHER 17 |
| 107 | 424364-2 | RUBBER WASHER 16 |
| 321144-6 | DEPTH GAUGE | |
| 821660-3 | PLASTIC CARYING CASE | |
| 452432-1 | SLIDE LATCH | |
| 806G57-9 | MAKITA MT LOGO LABEL | |
| 807W93-4 | M8700 PLASTIC CASE LABEL |
